| Place of Origin: | China |
|---|---|
| Brand Name: | Solar Roll Forming Machine |
| Model Number: | Adjustable C Channel |
| Minimum Order Quantity: | 1set |
| Price: | 150000 |
| Packaging Details: | Suitable for sea transportation |
| Delivery Time: | 30days |
| Payment Terms: | TT/LC |
| Supply Ability: | 100sets |
| Cutting Material: | Cr12 With Heat Treatment 58-60° | Hydraulic Cutting Power: | 30kw |
|---|---|---|---|
| Raw Material: | Galvalume, AZ150, AZ200 (UTS-650Mpa) | Cutting: | Post Track Cutting |
| Punching Stations: | 10 Units Hydraulic Punching System | Chang Size: | Flange And Width Is Adjust By PLC |
| Steel Thickness: | 0.8-1.2mm | Roller Stations: | About 18 Stations |
| Highlight: | High Efficiency Solar Roll Forming Machine,10 stations Solar Roll Forming Machine,Punching Solar Hat Roll Forming Machine |
||
The Solar Roll Forming Machine comes equipped with hydraulic cutting power of 11kw, making it an efficient and reliable machine for your production line. The hydraulic cutting system ensures that your products are cut to the exact size and shape required, with precision and accuracy. The machine also features a 60mm solid shaft diameter, which provides stability and strength to the machine during the roll forming process.
This roll forming machine is built to last. The raw material used to construct the machine is carefully selected to ensure that it can withstand the rigors of daily use and produce high-quality steel products. The cutting material used is Cr12 with heat treatment 58-60°, which ensures that your products are cut cleanly and accurately every time.
The Solar Roll Forming Machine is versatile and can be used to create a variety of products, including guide rail roll forming machine, track cutting, and strut roll forming machine. This makes it a valuable addition to any production line, as it allows for flexibility in product design and creation. With its user-friendly interface and easy-to-use controls, even those who are new to roll forming will find this machine easy to operate.
In summary, the Solar Roll Forming Machine is a reliable, durable, and efficient machine that can help you create high-quality steel products for your solar panel production needs. With its hydraulic cutting power, solid shaft diameter, and high-quality raw materials, this machine is designed to provide you with the best results every time. Whether you're creating guide rail roll forming machine, track cutting, or strut roll forming machine, this machine is sure to meet your needs.
| No | Specification of the material | |
| 1 | Suitable Material | |
| 2 | Thickness |
Standard thickness is:0.8-1.2mm But machine and afford max. 2.0mm |
| 3 | Tolerance |
Web/flange/lip size tolerance: ± 1 mm Holes/slots positional tolerance: ± 1 mm Length tolerance: ± 1.5mm/6m |
|
1 |
Machine structure | Iron cast by wire-electrode cutting,gear box drive |
| Change size | Was mentioned in the profile | |
| 2 | Total power |
About 83KW per hour AC motor all use China brand Servo motor is: Yaksawa |
| 3 | Roller stations | About 18stations + one station for rectify |
| 4 | Productivity |
Roll forming speed:40-50m/min Punching:about 30stock per min. |
| 5 | Drive system | By gear box |
| 6 | Diameter of shaft | ￠60mm solid shaft |
| 7 | Voltage | 415V 50Hz 3phases (Customized) |
| 8 | Container need | About 4X40HQ container |
| 9 |
Space request L x W x H |
Line: about 67mx3.5mx3.4m include punching(exactly size will be provide in 20 days after confirm order) |
| 10 | All AC motor | AC 3 Phase Induction motor to Chinese make |
The Solar Roll Forming Machine is a guide rail roll forming machine, which guarantees precision and accuracy in the final product. The machine is driven by a gear box, which ensures smooth and efficient operation. With a shaft diameter of 70mm solid shaft, the machine is built to last and handle the toughest of steel thicknesses ranging from 1.0-3.0mm.
The Solar Roll Forming Machine is perfect for scenarios where speed and efficiency are critical. With a main power of 15kw, the machine can handle heavy duty production and can be used for various applications such as roofing, wall cladding, and garage doors. The post track cutting feature ensures clean and precise cuts, saving time and reducing waste.
The Solar Roll Forming Machine is also convenient for transportation. It is packaged in a way that makes it suitable for sea transportation, ensuring that it arrives at its destination in perfect condition. With a supply ability of 100 sets and a delivery time of 30 days, the Solar Roll Forming Machine is readily available for purchase.
Overall, the Solar Roll Forming Machine is a great investment for any business looking to increase productivity and efficiency. With its full automatic features, guide rail roll forming machine, and drive by gear box, it is the perfect machine for various applications and scenarios.
Brand Name: Solar Roll Forming Machine
Model Number: Adjustable Hat Channel
Place of Origin: China
Minimum Order Quantity: 1set
Packaging Details: Suitable for sea transportation
Delivery Time: 60 days
Payment Terms: TT/LC
Supply Ability: 100 sets
Main Power: 15kwx2
Cutting: Post Track Cutting
Steel Thickness: 0.8-1.2mm
Shaft Diameter: 60mm Solid Shaft
Control System: PLC
Additional Features: Strut roll forming machine, Drive by Gear box
